| Processor |
TruePic™ X |
| Effective Resolution (approx.) |
20.4 MP |
| Hi Res (Yes / No) |
Yes |
| AF System |
Cross-type phase detection AF (1,053 points), Contrast AF (1,053 points) |
| Image Stabilisation |
Built-in 5-axis Up to 8 EV steps* |
| Construction |
Magnesium / Aluminium |
| ISO Sensitivity |
AUTO ISO: Customisable,LOW (approx.80) ‐ 102400 (Default: 200 - 25600) Manual ISO: LOW (approx.80, approx.100), 200 - 102400 (adjustable in 1/3, 1/2 or 1 EV steps) |
| Sequential Shooting |
Mechanical Shutter: 50fps C-AF & AE Tracking (RAW), Electronic Shutter: 120fps S-AF (RAW) |
| Top Shutter Speed |
Mechanical: 1/8000 sec Electronic (Silent): 1/32000 sec |
| Customisable Buttons |
9 Function Buttons |
| RAW Capture |
Yes (12-bit lossless compression) |
| Filter Video Quaility |
C4K: 60p, 50p, 30p, 25p, 24p | 4K: 60p, 50p, 30p, 25p, 24p | Full HD: 60p, 50p, 30p, 25p, 24p | High Speed Movie: 1920x1080 (FHD) / 240fps, 200fps, 120fps, 100fps, 100fps |
| Video Quality |
4K, C4K, Full HD, High Speed Movie FHD |
| Flash |
Compatible with all Olympus Flashes |
| Viewfinder Resolution Magnification / Coverage |
Eye-level OLED Electronic Viewfinder, approx. 5.76M dots Approx. 1.48x - 1.65x / Approx. 100% Field of View |
| Monitor |
3.0 inch Vari-angle Touch LCD (approx. 1.62M dots) |
| Focal Length (35mm equiv) |
N/A |
| Zoom Range |
|
| Max Aperture |
N/A |
| WiFi Function |
Yes |
| GPS |
Yes (Field Sensor System) |
| Tethered Shooting |
Yes (via USB cable / via WiFi) |
| Technology Innovation |
AE Bracketing, Focus Bracketing, Handheld Hi-Res, HDR, Intelligent Subject Detection, Keystone Compensation, Live Composite, Live ND, Live Time, Multi Exposure, Tripod Hi-Res, Silent |
| Weatherproof |
Dustproof, Freezeproof, Splashproof |
| Microphone |
Built-in Stereo φ3.5 stereo mini jack for external |
| USB Charging |
Yes |
| USB PD bus power |
Yes |
| Dimensions |
134.8mm(W) x 91.6mm(H) x 72.7mm(D) |
| Approx Weight (body only) |
511 |
