30sec. to 1/180000sec. |
|
|
S/M mode |
15min. to 1/180000sec. |
|
|
Bulb |
1sec. Fixed |
|
|
|
|
|
Electronic front curtain shutter |
P mode |
30sec. to 1/4000sec. |
|
|
A mode |
30sec. to 1/4000sec. |
|
|
S/M mode |
15min. to 1/4000sec. |
|
|
Bulb |
up to 60min. |
|
Mechanical + Electronic shutter |
P mode |
30sec. to 1/180000sec. |
|
|
A mode |
30sec. to 1/180000sec. |
|
|
S/M mode |
15min. to 1/180000sec. |
|
|
Bulb |
up to 60min. |
|
|
|
*Mechanical shutter works until 1/4000sec. |
|
|
|
|
|
E-front + Mechanical shutter |
P mode |
30sec. to 1/4000sec. |
|
(GFX: Electronic Front Curtain Shutter) |
A mode |
30sec. to 1/4000sec. |
|
|
S/M mode |
15min. to 1/4000sec. |
|
|
Bulb |
up to 60min. |
|
|
|
*Electronic front curtain shutter works until 1/2000sec. |
|
|
|
|
|
E-front + Mechanical + Electronic shutter |
P mode |
30sec. to 1/180000sec. |
|
(GFX: E-Front + Electronic Shutter) |
A mode |
30sec. to 1/180000sec. |
|
|
S/M mode |
15min. to 1/180000sec. |
|
|
Bulb |
up to 60min. |
|
|
|
*Electronic front curtain shutter works until 1/2000sec, Mechanical shutter works until 1/4000sec. |
|
|
|
*The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash can not be used. |
|
|
|
|
|
Movie |
8K/DCI8K |
|
|
|
6.2K |
1/4000sec. to 1/24 sec. |
|
|
5.8K |
|
|
|
5.4K |
|
|
|
4.8K |
|
|
|
4.6K(ANAMOR) |
|
|
|
4K/DCI4K |
1/4000sec. to 1/4 sec. |
|
|
FHD |
1/4000sec. to 1/4 sec. |
|
|
|
*Cannot choose slower shutter speed than framerate for some settings. |
|
Synchronized shutter speed for flash |
Mechanical shutter |
1/180sec. or slower |
|
|
Electronic shutter |
|
Continuous shooting |
CH |
Electronic shutter |
Approx. 20fps (1.29x Crop) |
|
No. of recordable frames |
JPEG |
416 frames |
|
|
Compressed RAW |
66 frames |
|
|
Lossless compressed RAW |
32 frames |
|
|
Uncompressed RAW |
17 frames |
|
|
Compressed RAW + JPEG |
21 frames |
|
|
Lossless compressed RAW + JPEG |
20 frames |
|
|
Uncompressed RAW + JPEG |
17 frames |
|
CH |
Electronic shutter |
Approx. 13fps (1.29x Crop) |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
94 frames |
|
|
Lossless compressed RAW |
25 frames |
|
|
Uncompressed RAW |
21 frames |
|
|
Compressed RAW + JPEG |
48 frames |
|
|
Lossless compressed RAW + JPEG |
31 frames |
|
|
Uncompressed RAW + JPEG |
19 frames |
|
CH |
Electronic shutter |
Approx. 10fps (1.29x Crop) |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
536 frames |
|
|
Lossless compressed RAW |
43 frames |
|
|
Uncompressed RAW |
23 frames |
|
|
Compressed RAW + JPEG |
61 frames |
|
|
Lossless compressed RAW + JPEG |
37 frames |
|
|
Uncompressed RAW + JPEG |
21 frames |
Continuous shooting |
CH |
Electronic shutter |
Approx. 13fps |
|
No. of recordable frames |
JPEG |
261 frames |
|
|
Compressed RAW |
46 frames |
|
|
Lossless compressed RAW |
21 frames |
|
|
Uncompressed RAW |
18 frames |
|
|
Compressed RAW+JPEG |
24 frames |
|
|
Lossless compressed RAW+JPEG |
20 frames |
|
|
Uncompressed RAW+JPEG |
19 frames |
|
CH |
Electronic shutter |
Approx. 8.9fps |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
68 frames |
|
|
Lossless compressed RAW |
28 frames |
|
|
Uncompressed RAW |
21 frames |
|
|
Compressed RAW+JPEG |
36 frames |
|
|
Lossless compressed RAW+JPEG |
23 frames |
|
|
Uncompressed RAW+JPEG |
21 frames |
|
CH |
Mechanical shutter |
Approx. 8.0fps |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
79 frames |
|
|
Lossless compressed RAW |
22 frames |
|
|
Uncompressed RAW |
20 frames |
|
|
Compressed RAW+JPEG |
30 frames |
|
|
Lossless compressed RAW+JPEG |
21 frames |
|
|
Uncompressed RAW+JPEG |
20 frames |
|
CL |
Mechanical shutter |
Approx. 5.0fps |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
1000+ frames |
|
|
Lossless compressed RAW |
56 frames |
|
|
Uncompressed RAW |
24 frames |
|
|
Compressed RAW+JPEG |
81 frames |
|
|
Lossless compressed RAW+JPEG |
27 frames |
|
|
Uncompressed RAW+JPEG |
21 frames |
|
CL |
|
Approx. 4.0fps |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
1000+ frames |
|
|
Lossless compressed RAW |
1000+ frames |
|
|
Uncompressed RAW |
29 frames |
|
CL |
|
Approx. 3.0fps |
|
No. of recordable frames |
JPEG |
1000+ frames |
|
|
Compressed RAW |
1000+ frames |
|
|
Lossless compressed RAW |
1000+ frames |
|
|
Uncompressed RAW |
60 frames |
|
Pre-shot |
Electronic shutter |
Approx. 20fps (1.29x Crop) |
|
No. of recordable frames |
While half press |
20 frames |
|
|
After full press |
135 frames |
|
|
Total |
155 frames |
|
Pre-shot |
Electronic shutter |
Approx. 13fps (1.29x Crop) |
|
No. of recordable frames |
While half press |
13 frames |
|
|
After full press |
177 frames |
|
|
Total |
190 frames |
|
Pre-shot |
Electronic shutter |
Approx. 10fps (1.29x Crop) |
|
No. of recordable frames |
While half press |
10 frames |
|
|
After full press |
240 frames |
|
|
Total |
250 frames |
|
Pre-shot |
Electronic shutter |
Approx. 13fps |
|
No. of recordable frames |
While half press |
13 frames |
|
|
After full press |
177 frames |
|
|
Total |
190 frames |
|
|
|
|
|
|
|
|
|
|
|
*Recordable frames depends on recording media |
|
|
|
*Speed of continuous shooting depends on shooting environment and shooting frames |
Drive Mode |
AE Bracketing |
|
2 frames |
|
|
|
3 frames |
|
|
|
5 frames |
|
|
|
7 frames |
|
|
|
9 frames |
|
|
|
*by 1/3EV step, up to ±3EV steps |
|
Filmsimulation bracketing |
|
Any 3 types of film simulation selectable |
|
Dynamic Range Bracketing |
|
100% |
|
|
|
200% |
|
|
|
400% |
|
ISO sensitivity Bracketing |
|
±1/3EV |
|
|
|
±2/3EV |
|
|
|
±1EV |
|
White Balance Bracketing |
|
±1 |
|
|
|
±2 |
|
|
|
±3 |
|
Focus Bracketing |
|
AUTO |
|
|
|
MANUAL |
|
Multiple Exposure |
|
Yes (Max. 9 frames) |
|
|
|
Additive |
|
|
|
Average |
|
|
|
Bright |
|
|
|
Dark |
|
HDR Mode |
|
AUTO |
|
|
|
200% |
|
|
|
400% |
|
|
|
800% |
|
|
|
800% + |
|
Advanced filter |
|
Toy camera |
|
|
|
Miniature |
|
|
|
Pop color |
|
|
|
High-key |
|
|
|
Low-key |
|
|
|
Dynamic tone |
|
|
|
Soft focus |
|
|
|
Partial color (Red / Orange / Yellow / Green / Blue / Purple) |
|
Pixel Shift Multi Shot |
HIGH RESOLUTION + ACCURATE COLOR |
|
|
|
ACCURATE COLOR |
|
Focus |
Mode |
|
Single AF |
|
|
|
Continuous AF |
|
|
|
MF |
|
Type |
|
Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF) |
|
Low-light Performance |
Contrast |
-4.0EV |
|
|
|
|
|
|
|
XF50mmF1.0 attached |
|
|
Phase Detection |
-7.0EV |
|
|
|
XF50mmF1.0 attached |
|
AF frame selection |
Single point AF |
13x9 / 25x17 (Changeable size of AF frame) |
|
|
Zone AF |
3x3 / 5x5 / 7x7 / Custom1-3 from 117 areas on 13×9 grid |
|
|
Wide/Tracking AF |
Yes (AF-S: Wide / AF-C: Tracking) |
|
|
All |
Yes |
|
Face/eye detection |
|
Yes |
|
Subject detection |
|
Yes (Animal/Bird/Automobile/Motorcycle&Bike/Airplane/Train) |
Flash |
Built-in flash |
|
Manual pop-up flash (Super Intelligent Flash) |
|
|
Guide Number |
approx. 3.9 (ISO100・m) |
|
|
Effective range(ISO1600) |
|
|
|
Sync. Mode |
1st Curtain |
|
|
|
2nd Curtain |
|
|
Flash Mode |
TTL (TTL AUTO / STANDARD / SLOW SYNC. ) |
|
|
|
MANUAL |
|
|
|
COMMANDER |
|
|
|
OFF |
Flash |
EF-X8 |
Guide Number |
|
|
|
Sync. Mode |
|
|
|
|
|
|
|
Flash Mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Shoe mount flash |
Sync. Mode |
1st Curtain |
|
|
|
2nd Curtain |
|
|
|
AUTO FP (HSS) |
|
|
Flash Mode |
TTL (TTL AUTO / STANDARD / SLOW SYNC. ) |
|
|
|
MANUAL |
|
|
|
MULTI *When EF-X500 is set |
|
|
|
OFF |
|
Synchronized terminal |
Sync. Mode |
|
|
|
|
|
|
|
Flash Mode |
|
Hot shoe |
|
|
Yes (Dedicated TTL Flash compatible) |
Viewfinder (Hybrid viewfinder) |
OVF |
|
|
|
|
Coverage of Frame Area v.s. Capturing Area |
|
|
|
Magnification |
|
Viewfinder |
EVF |
|
0.39 inch OLED Color Viewfinder |
|
|
|
Approx. 2.36 million dots |
|
|
Coverage of Viewing Area vs. Capturing Area |
Approx. 100% |
|
|
Eyepoint |
Approx. 17.5mm (from the Rear End of the Camera's Eyepiece) |
|
|
Diopter Adjustment |
-4~+2m-1 |
|
|
Magnification |
0.62x with 50mm Lens (35mm Equivalent) at infinity and Diopter set to -1.0m-1 |
|
|
Diagonal Angle of View |
approx. 31° (Horizontal angle of view: approx. 26° ) |
|
|
|
Built-In Eye Sensor |
LCD monitor |
|
|
3.0 inch Tilt-Type Touch Screen Color LCD Monitor |
|
Aspect Ratio |
|
3:2 |
|
Dots |
|
Approx. 1.84 million dots |
Touch Screen Mode |
Shooting Mode |
|
Shooting |
|
|
|
AF |
|
|
|
Focus Area |
|
|
|
OFF |
|
|
|
Double Tap Setting (ON/OFF) |
|
|
|
Touch Function Setting (ON/OFF) |
|
|
|
Touch Zoom (ON/OFF) |
|
|
|
EVF Touch Screen Area Setting |
|
|
|
|
|
Playback Mode |
|
Swipe |
|
|
|
Pinch-in / Pinch-out |
|
|
|
Double-tap |
|
|
|
Drag |
Movie recording |
File format |
MOV |
|
|
|
|
|
|
|
|
|
|
|
|
HEVC/H.265, Linear PCM (Stereo sound 24bit / 48KHz sampling) |
|
|
|
MPEG-4 AVC/H.264, Linear PCM (Stereo sound 24bit / 48KHz sampling) |
|
|
MP4 |
MPEG-4 AVC/H.264, AAC |
|
Movie compression |
|
All Intra |
|
|
|
Long GOP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6.2K(16:9) |
File size |
6240 x 3510 |
|
|
Frame rate |
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
|
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
DCI4K HQ(17:9) |
File size |
4096 x 2160 |
|
|
Frame rate |
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
|
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
4K HQ(16:9) |
File size |
3840 x 2160 |
|
|
Frame rate |
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
|
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
DCI4K(17:9) |
File size |
4096 x 2160 |
|
|
Frame rate |
59.94p |
|
|
|
50p |
|
|
|
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
|
|
|
|
|
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
|
Recording time |
|
|
|
|
|
|
4K(16:9) |
File size |
3840 x 2160 |
|
|
Frame rate |
59.94p |
|
|
|
50p |
|
|
|
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
|
|
|
|
|
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
|
Recording time |
|
|
|
|
|
|
Full HD(17:9) |
File size |
2048 x 1080 |
|
|
Frame rate |
59.94p |
|
|
|
50p |
|
|
|
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
|
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
|
Recording time |
|
|
Full HD(16:9) |
File size |
1920 x 1080 |
|
|
Frame rate |
59.94p |
|
|
|
50p |
|
|
|
29.97p |
|
|
|
25p |
|
|
|
24p |
|
|
|
23.98p |
|
|
Bitrate |
|
|
|
|
360Mbps |
|
|
|
200Mbps |
|
|
|
100Mbps |
|
|
|
50Mbps |
|
|
|
|
|
|
Recording time |
|
|
Full HD LP(17:9) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Recording time |
|
|
Full HDLP(16:9) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Recording time |
|
|
DCI4K(17:9) High speed rec. |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
Recording time |
|
|
|
|
|
|
4K(16:9) High speed rec. |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
Bitrate |
|
|
|
|
|
|
|
|
|
|
|
Recording time |
|
|
|
|
|
|
Full HD(17:9) High speed rec. |
File size |
2048 x 1080 |
|
|
Frame rate |
240p |
|
|
|
200p |
|
|
|
120p |
|
|
|
100p |
|
|
Bitrate |
|
|
|
|
360Mbps (recording) |
|
|
|
200Mbps (recording) |
|
|
Recording time |
|
|
|
|
|
|
Full HD(16:9) High speed rec. |
File size |
1920 x 1080 |
|
|
Frame rate |
240p |
|
|
|
200p |
|
|
|
120p |
|
|
|
100p |
|
|
Bitrate |
|
|
|
|
360Mbps (recording) |
|
|
|
200Mbps (recording) |
|
|
Recording time |
|
|
|
|
|
|
HD(16:9) |
File size |
|
|
|
Frame rate |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bitrate |
|
|
|
Recording time |
|
|
|
|
|
|
|
|
|
|
|
|
*For recording movies, use a SD memory card with UHS Speed Class 3 or higher. |
|
|
|
|
|
|
|
*For recording movies in 360Mbps, use a SD memory card with Video Speed Class 60 or higher. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
*Selectable bitrate will be changed depends on the setting. |
|
|
|
|
|
|
|
|
|
|
|
*Recording time can become short depending on the temperature and/or shooting conditions |
Scene Position mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Film simulation mode |
|
|
20 modes |
|
|
|
PROVIA/Standard |
|
|
|
Velvia/Vivid |
|
|
|
ASTIA/Soft |
|
|
|
Classic Chrome |
|
|
|
REALA ACE |
|
|
|
PRO Neg.Hi |
|
|
|
PRO Neg.Std |
|
|
|
Classic Neg. |
|
|
|
Nostalgic Neg. |
|
|
|
ETERNA/Cinema |
|
|
|
ETERNA BLEACH BYPASS |
|
|
|
ACROS |
|
|
|
ACROS + Ye Filter |
|
|
|
ACROS + R Filter |
|
|
|
ACROS + G Filter |
|
|
|
Black & White |
|
|
|
Black & White + Ye Filter |
|
|
|
Black & White + R Filter |
|
|
|
Black & White + G Filter |
|
|
|
Sepia |
Monochromatic Color |
|
|
Yes |
B & W ADJ. (Warm/Cool) |
|
|
|
Grain Effect |
Roughness |
|
STRONG, WEAK, OFF |
|
Size |
|
LARGE, SMALL |
Color Chrome Effect |
|
|
STRONG, WEAK, OFF |
Color chrome Blue |
|
|
STRONG, WEAK, OFF |
Smooth Skin Effect |
|
|
STRONG, WEAK, OFF |
Dynamic range setting |
Still |
|
AUTO / 100% / 200% / 400% |
|
|
ISO restriction |
DR100%: No limit、DR200%: ISO250 or more、DR400%: ISO500 or more |
|
Movie |
|
100% / 200% / 400% |
|
|
ISO restriction |
DR100%: No limit、DR200%: ISO250 or more、DR400%: ISO500 or more |
White balance |
Auto |
|
White Priority |
|
|
|
Auto |
|
|
|
Ambience Priority |
|
Custom |
|
Custom1 - 3 |
|
Color temperature selection |
|
2500K~10000K |
|
Preset |
|
Daylight |
|
|
|
Shade |
|
|
|
Fluorescent Light-1 |
|
|
|
Fluorescent Light-2 |
|
|
|
Fluorescent Light-3 |
|
|
|
Incandescent Light |
|
|
|
Underwater |
Clarity setting |
|
|
±5 steps |
Self-timer |
Still |
|
10sec. |
|
|
|
2sec. |
|
Movie |
|
10sec. |
|
|
|
5sec. |
|
|
|
3sec. |
Interval timer shooting |
|
|
Yes (Setting : Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing, Interval priority mode) |
Wireless transmitter |
Standard |
|
IEEE802.11a/b/g/n/ac (standard wireless protocol) |
|
Encryption |
|
WPA/WPA2 mixed mode, WPA3 |
|
Access mode |
|
Infrastructure |
Bluetooth |
Standartd |
|
Bluetooth Ver. 4.2 (Bluetooth low energy) |
|
Operating frequency (Center frequency) |
|
2402〜2480MHz |
Terminal |
Digital interface |
|
USB Type-C (USB3.2 Gen2x1) |
|
HDMI output |
|
HDMI Micro connector (Type D) |
|
LAN Terminal |
|
|
|
Others |
|
ø3.5mm, stereo mini connector (Microphone) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Hot shoe |
|
|
|
|
Power supply |
|
|
NP-W126S Li-ion battery (included) |
|
Battery life for still images |
Economy Mode |
Approx. 390 frames |
|
|
Normal Mode |
Approx. 305 frames |
|
|
|
|
|
|
|
|
|
|
|
*When XF35mmF1.4 R is set |
|
Actual battery life of movie capture |
8K |
|
|
|
6.2K |
Approx. 45min. (29.97p) |
|
|
4K |
Approx. 45min. (59.94p) |
|
|
Full HD |
Approx. 45min. (59.94p)、Approx. 50min. (120P) |
|
|
|
|
|
|
|
*Face detection is set to OFF |
|
Continuance battery life of movie capture |
8K |
|
|
|
6.2K |
Approx. 70min. (29.97p) |
|
|
4K |
Approx. 70min. (59.94p) |
|
|
Full HD |
Approx. 80min. (59.94p) |
|
|
|
|
|
|
|
*Face detection is set to OFF |
|
|
|
*Approximate number of frames or movie recording time that can be taken with a fully-charged based on CIPA Standard. |
Dimensions |
|
Width |
123.8mm |
|
|
Height |
84mm |
|
|
Depth |
48.8mm |
|
|
(Minimum Depth) |
(34.2mm) |
|
Excluding EVF |
Width |
|
|
|
Height |
|
|
|
Depth |
|
|
|
(Minimum Depth) |
|
Weight |
including battery and memory card |
|
Approx. 438g |
|
excluding battery and memory card |
|
Approx. 389g |
Operation Environment |
Operating Temperature |
|
0℃~+40℃ |
|
Operating Humidity |
|
10%~80% (no condensation) |
Starting up period |
|
|
Approx. 0.5sec. |
