| TECHNOLOGY |
|
| Scanner type |
Flatbed Scanner |
| Optical Density |
4.0Dmax |
| Colour Depth Input |
48Bits Colour, Output: 48Bits Colour |
| Dual Lens System |
scanning resolutions Super Resolution Lens 6,400x9,600 dpi, High Resolution Lens 4,800x9,600 dpi |
| Scanning Range |
(maximum) 216mm x 297mm (Horizontal x Vertical) |
| Paper Formats |
A4 |
| SCANNER |
|
| Optical Sensor |
Matrix CCD with Micro Lens Anti-reflection optical coatings on the CCD cover glass |
| Light Source |
White LED, IR LED with ReadyScan LED Technology |
| Scanning Method |
Fixed documents and moving carriage |
| Output Resolution |
25~12,800 (1 dpi step)dpi |
| SCANNING FEATURES |
|
| Image Improvement |
Grain reduction, Dust removal, Print Image Matching II, Color palette tool for Easy Color Fix, Backlight Correction, Colour Restoration, Unsharp Mask with Noise Reduction, De-Screening with Document Type Optimizer, Digital ICE Technologies (for film and photo), Tone Curve Adjustment with Histogram |
| CONNECTIVITY |
|
| Interfaces |
Hi-Speed USB - compatible with USB 2.0 specification |
| GENERAL |
|
| Supply Voltage |
AC220V - 240V, 50Hz - 60Hz |
| Product dimensions |
503 x 308 x 152mm (W x D x H) |
| Product weight |
6.6kg |
| Included Software |
Epson Copy Utility, Epson Event Manager, Epson Scan, LaserSoft Imaging™ SilverFast® SE 8 Plus, X-Rite i1 software |
| Compatible Operating Systems |
Mac OS X 10.6.8 or later, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP, SP2 or higher |
| Humidity Operation |
10% - 80%, Storage 10% - 85% |
| Temperature Operation |
5° C - 35° C, Storage-25° C - 60° C |
| |
|
| SCAN SPEED |
|
| Reflective scanning Colour |
(speed/best):12/15s/page , A4 Preview: 6s/page |
