| Body material |
Aluminium and polycarbonate resin with glass fibre** |
| Sensor* |
• 22.3 x 14.9 mm CMOS sensor
• RGB Color Filter Array
• Built-in fixed low-pass filter (with self-cleaning unit)
• 19 million total pixels
• 18 million effective pixels
• 3:2 aspect ratio |
| Image processor* |
DIGIC 4* |
| A/D conversion |
14 bit |
| Image Sizes ( Still) * |
RAW
• 5184 x 3456
• 3888 x 2592
• 2592 x 1728
JPEG
3:2
• 5184 x 3456
• 3456 x 2304
• 2592 x 1728
• 1920 x 1280*
• 720 x 480*
4:3*
• 4608 x 3456
• 3072 x 2304
• 2304 x 1728
• 1696 x 1280
• 640 x 480
16:9*
• 5184 x 2912
• 3456 x 1944
• 2592 x 1456
• 1920 x 1080
• 720 x 400
1:1*
• 3456 x 3456
• 2304 x 2304
• 1728 x 1728
• 1280x1280
• 480 x 480 |
| Image Sizes (Movie)* |
1920 x 1080 (29.97, 25, 23.976 fps)
1280 x 720 (59.94, 50 fps)
640 x 480 (59.94, 50 fps) |
| File formats (Still)* |
• JPEG (EXIF 2.3*) - Fine / Normal
• RAW
• M-RAW
• S-RAW
• RAW + JPEG
• M-RAW + JPEG
• S-RAW + JPEG |
| File formats (Movie)* |
MOV (Video: H.264, Sound: Linear PCM) |
| Lenses |
• Canon EF / EF-S lens mount
• 1.6x field of view crop |
| Dust reduction |
• EOS integrated cleaning system with fluorine coating
• Self-cleaning sensor unit (filter in front of sensor vibrates at high frequency at start-up and shutdown - can be disabled)
• Dust Delete Data - Data from a test shot is used to 'map' dust spots and can be later removed using Canon DPP Software |
| Auto focus |
• TTL-CT-SIR CMOS sensor
• 9 cross-type AF points (f/2.8 at centre)
• Center point additionally sensitive with lenses of F2.8 or faster
• AF working range: -0.5 - 18 EV (at 23°C, ISO 100) |
| Focus modes |
• One shot AF
• AI Servo AF
• AI Focus AF
• Manual focus |
| AF point selection |
• Auto : 9 point*
• Manual |
| AF Lock |
Locked when shutter button is pressed half way in One Shot AF mode or AF-ON button is pressed |
| Predictive AF |
• Up to 8 m |
| AF assist |
• Stroboscopic flash |
| AF microadjust |
No** |
| Metering |
• TTL full aperture metering with 63 zone Dual Layer (iFCL)
• Metering range: EV 1 - 20 EV |
| Metering modes |
• Evaluative metering (linked to all AF points)
• Partial (6.5% at center)*
• Spot metering (approx. 2.8% at center)*
• Center-weighted average |
| AE lock |
• Auto: One Shot AF with evaluative metering
• Manual: AE lock button |
| Exposure compensation* |
• +/-5.0 EV
• 0.3 or 0.5 EV increments |
| Exposure bracketing |
• +/- 3.0 EV
• 0.3 or 0.5 EV increments |
| Sensitivity * |
• Auto ISO (100-6400)
• ISO 100-6400 in 0.3 or 1.0 EV increments
• H (12800) expansion |
| Shutter |
• Focal-plane shutter
• 30 - 1/8000 sec
• 0.3 or 0.5 EV increments
• Flash X-Sync: 1/250 sec
• Bulb |
| Aperture values |
• 0.3 or 0.5 EV increments
• Actual aperture range depends on lens used |
| White balance |
• Auto
• Daylight
• Shade
• Cloudy
• Tungsten
• White Fluorescent light
• Flash
• Custom
• Kelvin (2500 - 10000 K in 100 K steps) |
| WB bracketing |
• +/-3 levels
• 3 images
• Blue / Amber or Magenta / Green bias |
| WB shift |
• Blue (-9) To Amber (+9)
• Magenta (-9) to Green (+9) |
| Picture style |
• Standard
• Portrait
• Landscape
• Neutral
• Faithful
• Monochrome
• User def. 1
• User def. 2
• User def. 3 |
| Custom image parameters |
• Sharpness: 0 to 7
• Contrast: -4 to +4
• Saturation: -4 to +4
• Color tone: -4 to +4
• B&W filter: N, Ye, Or, R, Gvan
• B&W tone: N, S, B, P, G |
| Image processing |
• Highlight tone priority
• Auto lighting optimizer (4 settings)
• Long exposure noise reduction
• High ISO noise reduction (4 settings)
• Auto correction of lens peripheral illumination (vignetting)
• Creative filters (Grainy B/W, Soft focus, Toy camera, Miniature effect) - during image Playback only RAW image processing - during image Playback only** |
| Color space |
• sRGB
• Adobe RGB |
| Viewfinder * |
• Eye-level pentaprism
• 96% frame coverage
• Magnification: 0.95x (-1 diopter with 50 mm lens at infinity)
• Eyepoint: 22 mm
• Interchangeable focusing screen Ef-A standard (2 other types optional)*
• Dioptric adjustment: -3.0 to +1.0 diopter |
| Mirror |
• Quick-return half mirror (transmission:reflection ratio 40:60)
• Mirror lock-up (once or multiple exposures) |
| Viewfinder info |
• AF points
• Focus confirmation light
• Shutter speed
• Aperture value
• ISO speed (always displayed)
• AE lock
• Exposure level/compensation
• Spot metering circle
• Exposure warning
• AEB.
• Flash ready
• High-speed sync
• FE lock
• Flash exposure compensation
• Red-eye reduction light
• White balance correction
• CF card information
• Monochrome shooting*
• Maximum burst (2 digit display)*
• Highlight tone priority (D+)
• Grid
• Dual Axis Electronic level* |
| LCD monitor |
• 3.0 " TFT LCD
• 1040,000 dots**
• 100% coverage
• 160 ° viewing angle
• Dual anti-reflection |
| LCD Live view |
• Live TTL display of scene from CMOS image sensor
• 100% frame coverage
• 30 fps frame rate
• Real-time evaluative metering using CMOS image sensor
• Best view or exposure simulation
• Silent mode
• Grid optional (x2)
• Magnify optional (5x or 10x at AF point)
• Three AF modes - Live mode/Quick mode/Face Detection
• Histogram
• Multi aspect ratios**
• Remote live view using EOS Utility 2.0 (via USB or WiFi/Ethernet using WFT) |
| Flash |
• Auto pop-up E-TTL II auto flash
• FOV coverage up to 17 mm (27 mm equiv.)*
• Guide number approx 13 m (ISO 100)*
• Cycle time approx. 3 sec
• Flash compensation +/-3.0 EV in 0.3 or 0.5 EV increments
• X-Sync: 1/250 sec |
| External flash |
• E-TTL II auto flash with EX-series Speedlites
• Wireles flash support *(no multi-group support*) |
| Shooting modes |
• Auto
• No Flash
• Creative Auto
• Portrait
• Landscape
• Close-up
• Sport
• Night Portrait
• Movie*
• Program AE
• Shutter priority AE
• Aperture priority AE
• Manual
• Custom |
| Drive modes |
• Single
• High-speed continuous
• Low-speed continuous
• Self-timer: 2sec + remote, 10sec + remote |
| Burst buffer * |
Approx. 5.3 fps (speed maintained for up to 58 JPEGs, 16 images (RAW)) |
| Orientation sensor |
Yes |
| Auto rotation |
• On (recorded and LCD display)
• On (recorded only)
• Off |
| Custom functions * |
20 Custom Functions with 59 settings |
| Menu languages |
• English
• German
• French
• Dutch
• Danish
• Portuguese
• Finnish
• Italian
• Norwegian
• Swedish
• Spanish
• Greek
• Russian
• Polish
• Czech
• Hungarian
• Romanian
• Ukrainian
• Turkish
• Arabic
• Thai
• Simplified Chinese
• Traditional Chinese
• Korean
• Japanese |
| Firmware |
User upgradable |
| Portrait grip* |
• Optional BG-E9 Battery Grip* |
| Connectivity |
• USB 2.0 Hi-Speed
• Video output (PAL/ NTSC)
• HDMI connector
• E3 type wired remote control
• External microphone (3.5mm Stereo mini jack) |
| Storage** |
• SD, SDHC, SDXC cards |
| Power* |
• Lithium-Ion LP-E6 rechargeable battery (supplied & charger)
• Built in battery (date/time backup)
• Optional AC adapter |
| Wireless connectivity |
Compatible with Eye-Fi cards |
| Dimensions** |
145 x 106 x 79 mm (5.7 x 4.2 x 3.1 in) |
| Weight ** |
• Including battery and memory card: 755 g (1.6 lb) |
