| Year Introduced |
2016 |
|
| Megapixels |
18.0 |
|
| Total Pixels |
18.7 |
|
| Sensor Size |
22.3 x 14.9mm |
|
| Pixel Dimensions |
5184 x 3456 |
|
| Pixel Size |
4.30µm |
|
| Diffraction-Limited Aperture |
f/6.9 |
|
| Sensor Stabilization |
N |
|
| Lens Mount |
EF, EF-S, TS-E, MP-E |
|
| FOVCF |
1.6x |
|
| Image Processor |
DIGIC 4+ |
|
| |
| Type |
TTL-CT-SIR with a CMOS sensor |
|
| Points |
9 AF points (f/5.6 cross type at center) |
|
| Working Range |
Center AF point: EV 0 -18 (at 23°C & ISO100)
Other AF points: EV 1 -18 (at 23°C & ISO100) |
|
| Modes |
One-Shot AF
Predictive AI Servo AF (AI Servo AF II)
AI Focus AF |
|
| Point Selection |
Automatic selection, Manual selection |
|
| Microadjustment |
No |
|
| |
| Metering Modes |
TTL full aperture metering with 63-zone SPC
(1) Evaluative metering (linked to all AF points)
(2) Partial metering at center (approx. 10% of viewfinder)
(3) Center weighted average metering |
|
| Metering Range |
EV 1 – 20 (at 23°C with 50mm f/1.4 lens ISO100) |
|
| Exposure Comp |
+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB) |
|
| AEB |
3 shots +/- 2 EV, 1/2 or 1/3-stop increments |
|
| ISO Sensitivity |
AUTO (100-6400), 100-6400 in 1-stop increments
ISO can be expanded to H: 12800
During Movie shooting: Auto (100-6400), 100-6400 (Whole stop increments) |
|
| Shutter Speed |
30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode) |
|
| WB Settings |
AWB, Daylight, Shade, Cloudy, Tungsten, White Fluorescent light, Flash, Custom
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/ Green +/-9 |
|
| Custom WB |
Yes, 1 setting can be registered |
|
| |
| Type |
Pentamirror |
|
| Coverage |
Approx. 95% |
|
| Magnification |
Approx. 0.80x |
|
| Eyepoint |
Approx. 21mm |
|
| Information |
AF information: AF points, focus confirmation light
Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, exposure warning, AEB
Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light
Image information: Highlight tone priority (D+), monochrome shooting, maximum burst (1 digit display), White balance correction, SD card information |
|
| DOF Preview |
Yes, assigned to SET button with C.Fn-9-4 |
|
| Eyepiece Shutter |
On strap |
|
| |
| Type |
7.5cm (3.0") TFT, approx. 920k dots |
|
| Coating |
|
|
| Brightness Adj |
Adjustable to one of seven levels |
|
| Display Options |
(1) Quick Control Screen
(2) Camera settings |
|
| |
| Built-in GN |
9.2 (ISO 100, meters) |
|
| Built-in Coverage |
Up to 17mm focal length (35mm equivalent: 28mm) |
|
| Built-in Recycle Time |
Approx. 2 seconds |
|
| Modes |
Auto, Manual Flash On/off |
|
| X-Sync |
1/200sec |
|
| Exposure Compensation |
+/- 2EV in 1/2 or 1/3 increments |
|
| Hot Shoe/PC Terminal |
Yes / No |
|
| External Flash Comp |
E-TTL II with EX series Speedlites, wireless multi-flash support (with optional accessory) |
|
| External Flash Control |
Via camera menu screen, except for wireless radio flash |
|
| |
| Shooting Modes |
Scene Intelligent Auto, No Flash, Creative Auto, Portrait, Landscape, Close-up, Sports, Food, Night Portrait, Movie, Program AE , Shutter priority AE, Aperture priority AE, Manual (Stills and Movie) |
|
| Picture Styles |
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3) |
|
| Image Processing |
Highlight Tone Priority
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings)
Auto Correction of Lens Peripheral illumination
Basic+ (Shoot by ambience selection, Shoot by lighting or scene type)
Creative filters (Grainy B/W, Soft focus, Toy camera, Miniature effect, Fish-eye) - during image Playback only |
|
| Drive Modes |
Single, Continuous, Self timer (2s, 10s+remote, 10s + continuous shots 2-10) |
|
| Continuous Shooting |
Max. Approx. 3fps for approx. 1110 JPEG images, 6 images RAW |
|
| Shutter Lag |
|
|
| Viewfinder Blackout |
N/A |
|
| |
| FrameRate |
30 fps |
|
| Focusing |
Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Quick mode, Live mode |
|
| Metering |
Real-time evaluative metering with image sensor
Active metering time can be changed |
|
| Display Options |
Grid overlay, Histogram |
|
| |
| Still ImageType |
JPEG: Fine, Normal (Exif 2.30 compliant) / Design rule for Camera File system (2.0)
RAW: RAW (14bit, Canon original RAW 2nd edition), Digital Print Order Format [DPOF] Version 1.1 compliant |
|
| Image Size |
JPEG 3:2: (L) 5184x3456, (M) 3456x2304, (S1) 2592x1728, (S2) 1920x1280, (S3) 720x480
JPEG 4:3: (L) 4608x3456, (M) 3072x2304, (S1) 2304x1728, (S2) 1696x1280, (S3) 640x480
JPEG 16:9: (L) 5184x2912, (M) 3456x1944, (S1) 2592x1456 (S2) 1920x1080, (S3) 720x400
JPEG 1:1: (L) 3456x3456, (M) 2304x2304, (S1) 1728x1728, (S2) 1280x1280, (S3) 480x480
RAW: (RAW) 5184x3456 |
|
| Movie Type |
MOV (Video: H.264, Sound: Linear PCM, recording level can be manually adjusted by user) |
|
| Movie Size |
1920 x 1080 (29.97, 25, 23.976 fps)
1280 x 720 (59.94, 50 fps)
640 x 480 (30, 25 fps) |
|
| Movie Length |
Max duration 29min 59sec, Max file size 4GB |
|
| |
| Wireless Features |
Built-in Wi-Fi and NFC |
|
| GPS |
via optional GP-E2 GPS Receiver |
|
| Custom Functions |
11 Custom Functions with 33 settings |
|
| LCD Panel / Illumination |
No / No |
|
| Water & Dust Resistance |
|
|
| Sound Memo |
No |
|
| |
| Computer Interface |
Hi-Speed USB |
|
| Other Interface |
Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (HDMI-CEC compatible) |
|
| |
| Memory Type |
SD card, SDHC card or SDXC card |
|
| |
| Battery |
Rechargeable Li-ion Battery LP-E10 |
|
| Battery Life |
Approx. 500 (at 23°C, AE 50%, FE 50%)
Approx. 410 (at 0°C, AE 50%, FE 50%) |
|
| Power Supply Battery Chargers |
AC Adapter Kit ACK-E10, Battery charger LC-E10, LC-E10E |
|
| |
| Body Materials |
Carbon fiber/glass fiber and polycarbonate resin |
|
| Shutter Durability Rating |
N/A |
|
| Operating Environment |
0 – 40 °C, 85% or less humidity |
|
| Dimensions Inches |
5.08 x 3.99 x 3.06" (129.0 x 101.3 x 77.6mm) |
|
| CIPA Weight |
17.1 oz (485g) |
|
| |
| Viewfinder |
Eyecup Ef, E-series Dioptric Adjustment Lens with Rubber Frame Ef, Eyepiece Extender EP-EX15II, Angle Finder C, Magnifier MG-Ef |
|
| Wireless File Transmitter |
|
|
| Compatible Lenses |
All EF, EF-S, TS-E and MP-E lenses |
|
| Battery Grip |
|
|
| Remote |
Remote Switch RS-60E3 |
|
| Other |
Hand Strap E2, GPS Receiver GP-E2, HDMI Cable HTC-100 |
