Effective pixels
|
16.0 million
|
|
|
(Image processing may reduce the number of effective pixels.)
|
|
Image sensor
|
1/2.3-in. type CMOS
|
|
|
Total pixels: approx. 16.79 million
|
|
Lens
|
NIKKOR lens with 125x optical zoom
|
|
Focal length
|
4.3-539 mm (angle of view equivalent to that of 24-3000 mm lens in 35mm [135] format)
|
|
f/-number
|
f/ 2.8-8
|
|
Construction
|
17 elements in 12 groups (5 ED lens elements and 1 super ED lens element)
|
|
Digital zoom magnification
|
|
|
Digital zoom magnification
|
Up to 4x (angle of view equivalent to that of approx. 12000 mm lens in 35mm [135] format)
|
|
|
Up to 3.6x when recording movies with 2160/30p (4K UHD) or 2160/25p (4K UHD)
|
|
Vibration reduction
|
Lens shift (still images)
|
|
|
Combination of lens shift and electronic VR (movies)
|
|
Autofocus
|
Contrast-detect AF
|
|
Focus range
|
[W]: Approx. 30 cm (1 ft)-∞
|
|
|
[T]: Approx. 7.0 m (23 ft)-∞
|
|
|
Macro close-up mode: Approx. 1 cm (0.4 in.)-∞ (wide-angle position), Approx. 7.0 m (23 ft)-∞ (telephoto position)
|
|
|
(All distances measured from center of front surface of lens)
|
|
Focus-area selection
|
Target finding AF, face priority, manual (spot), manual (normal), manual (wide), subject tracking
|
|
Viewfinder
|
Electronic viewfinder, 1 cm (0.39-in.), approx. 2359k-dot OLED with the diopter adjustment function (-3- +3 m-1)
|
|
Frame coverage (shooting mode)
|
Approx. 99% horizontal and vertical (compared to actual picture)
|
|
Frame coverage (playback mode)
|
Approx. 100% horizontal and vertical (compared to actual picture)
|
|
Monitor
|
8.1 cm ( 3.2 -in.), approx. 921k-dot (RGB) wide viewing angle TFT LCD with anti-reflection coating and 5-level brightness adjustment, vari-angle TFT LCD
|
|
Frame coverage (shooting mode)
|
Approx. 99% horizontal and vertical (compared to actual picture)
|
|
Frame coverage (playback mode)
|
Approx. 100% horizontal and vertical (compared to actual picture)
|
|
Storage Media
|
SD , SDHC , SDXC
|
|
File system
|
DCF and Exif 2.31 compliant
|
|
File formats
|
Still images: JPEG, RAW (NRW) (Nikon’s own format)
|
|
|
Movies: MP4 (Video: H.264/MPEG-4 AVC, Audio: AAC stereo)
|
|
Image size (pixels)
|
|
|
Still images
|
16 M 4608x3456
|
|
|
8 M 3264x2448
|
|
|
4 M 2272x1704
|
|
|
2 M 1600x1200
|
|
|
16:9 12 M 4608x2592
|
|
|
3:2 14 M 4608x3072
|
|
|
1:1 12 M 3456x3456
|
|
Movies
|
2160/30p (4K UHD)
|
|
|
2160/25p (4K UHD)
|
|
|
1080/30p
|
|
|
1080/25p
|
|
|
1080/60p
|
|
|
1080/50p
|
|
|
720/30p
|
|
|
720/25p
|
|
|
720/60p
|
|
|
720/50p
|
|
|
HS 480/4x
|
|
|
HS 720/2x
|
|
|
HS 1080/0.5x
|
|
Exposure
|
|
|
ISO sensitivity (Standard output sensitivity)
|
ISO 100* to 1600
|
|
|
* The lowest ISO sensitivity in Movie manual mode is ISO 125.
|
|
|
ISO 3200, 6400 (available when using P, S, A, M, or Movie manual mode)
|
|
Metering mode
|
Matrix, center-weighted, spot
|
|
Exposure control
|
Programmed auto exposure with flexible program, shutter-priority auto, aperture-priority auto, manual, exposure bracketing, exposure compensation (–2.0- +2.0 EV in steps of 1/3 EV)
|
|
Shutter
|
Mechanical and CMOS electronic shutter
|
|
Shutter speed
|
1/4000*-1 s
|
|
|
1/4000*-30 s (when ISO sensitivity is 100 in M mode)
|
|
|
* At wide-angle position, with largest f-number setting (smallest aperture)
|
|
|
Bulb and Time setting (can be set when ISO sensitivity is 100 in M mode): Up to 60 seconds
|
|
|
1/8000-1/30 s (when recording movies)
|
|
Flash sync speed
|
Synchronises with all shutter speeds
|
|
Self-timer
|
Can be selected from 10 s and 3 s
|
|
Aperture
|
|
|
Type
|
Electronically-controlled 7-blade iris diaphragm
|
|
Range
|
10 steps of 1/3 EV (W) (A, M mode)
|
|
Flash
|
|
|
Range of built-in flash (approx.) (ISO sensitivity: Auto)
|
[W]: Approx. 0.3-12 m (12 in.-41 ft)
|
|
|
Approx. 5.0–8.0 m (17–26 ft) (focal length equivalent to that of 2000 mm lens in 35mm [135] format)
|
|
|
When focal length is equivalent to that of 3000 mm lens in 35mm [135] format: Approx. 7.0-8.2 m (23-26 ft) (ISO sensitivity: 3200), Approx. 7.0-11 m (23-38 ft) (ISO sensitivity: 6400)
|
|
Flash control
|
TTL auto flash with monitor preflashes
|
|
Flash exposure compensation
|
In steps of 1/3 EV in the range between –2 and +2 EV
|
|
Accessory shoe
|
|
|
Accessory shoe
|
ISO 518 hot-shoe with sync and data contacts and safety lock
|
|
Interface
|
|
|
USB connector
|
Micro-USB connector (Do not use any USB cable other than the included UC-E21 USB Cable.), Hi-Speed USB
|
|
|
Supports Direct Print (PictBridge)
|
|
HDMI output connector
|
HDMI micro connector (Type D)
|
|
External microphone connector
|
Stereo mini-pin jack (3.5 mm diameter; plug-in power supported)
|
|
Accessory terminal
|
Compatible with the following accessories (available separately): MC-DC2 Remote Cord
|
|
|
WR-R10/WR-1 Wireless Remote Controller
|
|
Wi-Fi (Wireless LAN)
|
|
|
Standards
|
IEEE 802.11b/g (standard wireless LAN protocol)
|
|
Operating frequency
|
2412-2462 MHz (1-11 channels)
|
|
Maximum output power
|
9.2 dBm (EIRP)
|
|
Authentication
|
Open system, WPA2-PSK
|
|
Bluetooth
|
|
|
Communication protocols
|
Bluetooth Specification Version 4.1
|
|
Operating frequency
|
Bluetooth: 2402-2480 MHz
|
|
Power sources
|
|
|
Power sources
|
One EN-EL20a Rechargeable Li-ion Battery (included)
|
|
|
EH-5b/EH-5c AC Adapter; requires EP-5C Power Connector (available separately)
|
|
Charging time
|
Approx. 3 h (when using EH-73P/EH-73PCH Charging AC Adapter and when no charge remains)
|
|
Battery life*1
|
|
|
Still Images
|
Approx. 250 shots when using EN-EL20a
|
|
Battery life of movie recording (actual battery life for recording)*2
|
Approx. 1 h 20 min when using EN-EL20a
|
|
Tripod socket
|
|
|
Tripod socket
|
1/4 (ISO 1222)
|
|
Dimensions (WxHxD)
|
Approx. 146.3 x 118.8 x 181.3 mm
|
|
|
(excluding projections)
|
|
Weight
|
Approx. 1415 g (including battery and memory card)
|
|
Operating environment
|
|
|
Temperature
|
0°C-40°C
|
|
Humidity
|
85% or less (no condensation)
|
