| Lens Mount |
L-Mount
|
| Sensor Resolution |
Actual: 45.9 Megapixel
|
| Effective: 44.3 Megapixel |
| Image Sensor |
35.8 x 23.9 mm (Full-Frame) CMOS
|
| Sensor Crop (35mm Equivalent) |
Crop Factor: 1x
|
| Additional Modes: 1.5x |
| *Additional Crop Occurs in Select Video Modes |
| Image Stabilization |
Sensor-Shift, 5-Axis
|
| Capture Type |
Stills & Video
|
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
| Shutter Speed |
Electronic Front Curtain Shutter
|
| 1/2000 to 60 Seconds |
| Mechanical Shutter |
| 1/8000 to 60 Seconds |
| Electronic Shutter |
| 1/8000 to 60 Seconds in Aperture Priority Mode |
| 1/16000 to 60 Seconds in Shutter Priority Mode |
| 1/10000 to 1/25 Seconds in Movie Mode |
| Bulb/Time Mode |
Bulb Mode (Up to 30 Minutes)
|
| ISO Sensitivity Range |
|
| 40 to 102,400 in Auto Mode |
| Video |
| 200 to 51,200 in Auto Mode |
| Metering Method |
Center-Weighted Average, Highlight Weighted, Multiple, Spot
|
| Exposure Modes |
Aperture Priority, Auto, Manual, Program, Shutter Priority
|
| Exposure Compensation |
-5 to +5 EV (1/3 EV Steps)
|
| Metering Range |
0 to 18 EV
|
| White Balance |
Presets: AWB, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set 1, White Set 2, White Set 3, White Set 4
|
| Continuous Shooting |
Up to 40 fps at Maximum Resolution for up to 40 Frames (Raw)
|
| Interval Recording |
Yes
|
| Self-Timer |
2/10-Second Delay
|
| Aspect Ratio |
1:1, 2:1, 3:2, 4:3, 16:9, 65:24
|
| Image File Format |
JPEG, Raw
|
| Internal Recording Modes |
H.264 Long GOP/MOV 4:2:0 10-Bit
|
| UHD 8K (7680 x 4320) at 29.97 fps [300 Mb/s] |
| UHD 8K (7680 x 4320) at 23.98 fps [300 Mb/s] |
| H.264 Long GOP/MOV 4:2:2/4:2:0 8/10-Bit |
| DCI 4K (4096 x 2160) at 23.98 fps [400 Mb/s] |
| DCI 4K (4096 x 2160) at 23.98 fps [150 Mb/s] |
| DCI 4K (4096 x 2160) at 23.98 fps [100 Mb/s] |
| DCI 4K (4096 x 2160) at 120 fps [300 Mb/s] |
| DCI 4K (4096 x 2160) at 59.94 fps [800 Mb/s] |
| DCI 4K (4096 x 2160) at 59.94 fps [600 Mb/s] |
| DCI 4K (4096 x 2160) at 59.94 fps [200 Mb/s] |
| DCI 4K (4096 x 2160) at 59.94 fps [150 Mb/s] |
| DCI 4K (4096 x 2160) at 47.95 fps [600 Mb/s] |
| DCI 4K (4096 x 2160) at 47.95 fps [800 Mb/s] |
| DCI 4K (4096 x 2160) at 47.95 fps [200 Mb/s] |
| DCI 4K (4096 x 2160) at 29.97 fps [400 Mb/s] |
| DCI 4K (4096 x 2160) at 29.97 fps [150 Mb/s] |
| DCI 4K (4096 x 2160) at 29.97 fps [100 Mb/s] |
| H.264 Long GOP/MOV 4:2:2/4:2:0 8/10-Bit |
| UHD 4K (3840 x 2160) at 23.98 fps [150 Mb/s] |
| UHD 4K (3840 x 2160) at 23.98 fps [100 Mb/s] |
| UHD 4K (3840 x 2160) at 59.94 fps [800 Mb/s] |
| UHD 4K (3840 x 2160) at 59.94 fps [600 Mb/s] |
| UHD 4K (3840 x 2160) at 59.94 fps [200 Mb/s] |
| UHD 4K (3840 x 2160) at 59.94 fps [150 Mb/s] |
| UHD 4K (3840 x 2160) at 47.95 fps [600 Mb/s] |
| UHD 4K (3840 x 2160) at 47.95 fps [800 Mb/s] |
| UHD 4K (3840 x 2160) at 47.95 fps [200 Mb/s] |
| UHD 4K (3840 x 2160) at 29.97 fps [400 Mb/s] |
| DCI 4K (3840 x 2160) at 29.97 fps [150 Mb/s] |
| UHD 4K (3840 x 2160) at 29.97 fps [100 Mb/s] |
| UHD 4K (3840 x 2160) [400 Mb/s] |
| External Recording Modes |
USB
|
| UHD 4K (3840 x 2160) at 29.97 fps |
| UHD 4K (3840 x 2160) at 25 fps |
| HD (1280 x 720) at 25/50 fps |
| HD (1280 x 720) at 29.97/59.94 fps |
| HD (1280 x 720) at 25/50 fps |
| Fast-/Slow-Motion Support |
Yes
|
| Gamma Curve |
Panasonic V-Log
|
| Recording Limit |
No
|
| IP Streaming |
No
|
| Built-In Microphone |
Stereo
|
| Audio Recording |
MOV: 2-Channel 24-Bit 48 kHz LPCM Audio
|
| MP4: 2-Channel 16-Bit 48 kHz AAC Audio |
| Media/Memory Card Slot |
Slot 1: CFexpress Type B
|
| Slot 2: SD/SDHC/SDXC |
| Video I/O |
1x HDMI Output
|
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
|
| 1x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O |
1x USB-C Input
|
| Other I/O |
1x USB-C (USB 3.2 / 3.1 Gen 1) Data Output (Shared with Power Input)
|
| Wireless |
2.4 GHz Wi-Fi 5 (802.11ac), Bluetooth 5.0
|
| Mobile App Compatible |
Yes: Android & iOS
|
| App Name: LUMIX Lab/LUMIX Flow |
| Global Positioning (GPS, GLONASS, etc.) |
GPS
|
| *Via Connected Smartphone |
| Display Size |
3"
|
| Resolution |
1,840,000 Dot
|
| Display Type |
Tilting Non-Touchscreen LCD
|
| Type |
Electronic (OLED)
|
| Resolution |
5,760,000 Dot
|
| Eye Point |
21 mm
|
| Coverage |
100%
|
| Magnification |
Approx. 0.78x
|
| Focus Type |
Auto and Manual Focus
|
| Focus Mode |
Automatic, Continuous-Servo AF, Manual Focus
|
| Autofocus Sensitivity |
-6 to +18 EV
|
| Built-In Flash/Light |
No
|
| Flash Modes |
Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Slow Sync, Slow Sync/Red-Eye Reduction
|
| Maximum Sync Speed |
1/250 Second
|
| Flash Compensation |
-3 to +3 EV (1/3 EV Steps)
|
| Dedicated Flash System |
TTL
|
| External Flash Connection |
Shoe Mount, PC Terminal
|
| Battery |
1x Rechargeable Lithium-Ion, 7.2 VDC, 2200 mAh (Included)
|
| Shoe Mount |
1x Hot Shoe
|
| Tripod Mounting Thread |
1x 1/4"-20 Female (Bottom)
|
| Accessory Mounting Thread |
1x 1/4"-20 on Camera Body
|
| Material of Construction |
Magnesium Alloy
|
| Operating Conditions |
-14 to 104°F / -25 to 40°C at 10 to 80% Humidity (Recommended)
|
| Dimensions (W x H x D) |
102.36 x 134.37 x 91.69 mm
|
| Weight |
0.79 kg (With Battery)
|
| 0.71 kg (Body Only) |
