OM System M.Zuiko ED 12-40mm F2.8 Pro II Lens

Product Code: 117059

inc GST
Increase value Decrease value
Found a better price? We'll match it!* Price Match Now
  • Product Description
  • Specifications
  • What's in the Box?

M.Zuiko Digital ED 12-40mm F2.8 PRO II

Clearer, sharper imaging than ever before

Key Features:
  • Reliable weather-resistant performance
  • 35mm equivalent: 24-80mm
  • Further improved high image quality and a compact, lightweight design in a standard zoom lens with a fixed maximum aperture of F2.8
  • Advanced IP53 dustproof and splashproof performance, and freezeproof performance to -10°C
  • Fluorine coating added
  • Excellent resolution across the entire zoom range
  • Closest focusing distance of 20 cm (at all focal distances),
This model uses an optical design with 14 elements in 9 groups (1 EDA lens, 2 aspherical lens, 1 DSA lens, 2 ED lens, 1 HD lens, 2 HR lens) with 4 aspherical lenses including a DSA lens effectively placed to achieve a compact, lightweight form and superior depictive performance of an M.Zuiko PRO lens. Effectively compensating for aberrations that occur when zooming, results in high resolution from the centre to the edges of the frame across the entire zoom range, from wide-angle 24mm equivalent1 to mid-telephoto 80mm equivalent1. This high-performance lens fully utilises the high image quality performance of the camera body when using High Res Shot mode.
The latest manufacturing techniques suppress surface scattering on aspherical lenses, significantly reducing flares compared to conventional products, resulting in clearer depictive performance. Optimal placement of coating, including ZERO (Zuiko Extra-low Reflection Optical) coating, improves resistance to backlighting.

Suited to LANDSCAPE, PORTRAIT, TRAVEL and ASTRO photographers.
M.ZUIKO DIGITAL ED 12-40mm F2.8 PRO Ⅱ
Specifications
Focal Length 12-40mm
     35mm Equivalent Focal Length      24-80mm
Lens Construction 14 elements in 9 groups
  (1 EDA lens, 2 aspherical lens, 1 DSA lens, 2 ED lens, 1 HD lens, 2 HR lens)
Splashproof Type / Dustproof IEC Standard publication 60529 IP53
(applies when the lens is used with OM SYSTEM (OLYMPUS) splashproof body) / Dustproof construction
Focusing System High-speed imager AF (MSC)
Angle of View 84-30 degree
Closest Focusing Distance 0.2m
Maximum Image Magnification Wide:0.11x / Tele: 0.3x
     35mm Equivalent Max. Image Magnification      Wide:0.21x / Tele: 0.6x
Minimum Field Size Wide:161.7×121.5mm/Tele:58 x 44  mm

Number of Blades 7 (circular aperture diaphragm)
Maximum Aperture F2.8
Minimum Aperture F22
Filter Size Diameter 62mm
Dimensions Diameter 69.9 × 84 mm
Weight 382g (without lens cap, lens rear cap and lens hood)
Box Contents Lens cap (LC-62G), lens rear cap, lens hood (LH-66D), wrapping cloth, instruction manual, warranty card
Specifications and design are subject to change without notice.
Separately Availbale Accessories Protection filter (PRF-ZD62PRO)
Lens case (LSC-0811)
LH-66D Lens Hood
Dimensions Diameter 79.7 x 36.7 mm
Weight 22.2 g

LC-62G Lens Cap
Dimensions Diameter 64.2 x 9.0 mm
Weight 13.4 g
  • Lens cap (LC-62G)
  • Lens rear cap
  • Lens hood (LH-66D)
  • wrapping cloth
  • instruction manual
  • warranty card
