| Image sensor |
Full-frame/FX-format partially stacked CMOS sensor |
| Effective pixels |
24.5 million |
| Lens mount |
Z mount |
| ISO sensitivity |
Video mode: ISO 100-51200 (Extended: Up to ISO 204800 equiv.) (HLG tone mode: ISO 400-51200) (N-Log tone mode: Lo 2.0-0.3,ISO 800-51200) (Video file type R3D NE 12 bit: Base ISO selectable between 800 and 6400) |
| |
Photo mode: ISO 100-64000 (Extended: Down to ISO 50 equiv., up to ISO 204800 equiv.) |
| Shutter |
Electronic shutter 1/16000-30 s, -900 s (mode M), flash sync speed of 1/60 s, Bulb, Time |
| Frame size/rate |
5.4K/59.94p,50p,29.97p,25p,23.976p, 4K UHD/119.88p,100p, 59.94p,50p,29.97p,25p,23.976p, FHD/239.76p,200p, 119.88p,100p, 59.94p,50p,29.97p,25p,23.976p |
| Frame size/rate |
6K/59.94p,50p,29.97p,25p,23.976p, 4K (4032×2268) /59.94p,50p,29.97p,25p,23.976p, 4K (3984×2240) /119.88p,100p, 59.94p,50p,29.97p,25p,23.976p 6K/59.94p,50p, 4K/119.88p,100p are only available in N-RAW and R3D NE. |
| Video file type(extension) |
.R3D, .NEV, .MOV, .MP4 (H.264/AVC (8bit)) |
| Video compression |
N-RAW (12 bit), R3D NE (12 bit), Apple ProRes RAW HQ (12 bit), Apple ProRes 422 HQ (10 bit), H.265/HEVC (8 bit/10 bit), H.264/AVC (8 bit) (Apple ProRes LT will be added in the future Firmware Update) |
| Tone mode |
SDR, HLG, N-Log, Log3G10 (only available in R3D NE) |
| Dynamic range |
15+ stops (Log3G10: In-house testing) |
| Audio recording device |
Built-in microphone or external microphone can be used; external audio devices can be used via line input, audio directivity (OZO Audio), audio input sensitivity adjustable; attenuator, frequency response, and wind noise Reduction functions |
| Audio recording format |
Linear PCM (48 KHz, 24-bit/32-bit float, recorded in NEV, R3D, or MOV video file types) or AAC (48 KHz, 16 bit, for videos recorded in MP4 format) |
| Media slots |
CFexpress (Type B), XQD, microSD (Secure Digital), and UHSRe-I compliant microSDHC and microSDXC memory cards, dual card slots |
| Media capacity |
Up to approx. 125 minutes (In R3D NE 12bit, 25°F/77°F,connected to an external power source) |
| Metering mode |
Video mode: Matrix, center-weighted, highlight-weighted; Photo mode: Matrix, center-weighted, spot, highlight-weighted |
| Autofocus |
Hybrid focal-plane phase-detection/contrast AF, 273 focus points (in photo mode with single-point AF), 90%× 90% coverage, pixel interpolation, subject detection (people (eyes, face, head, upper body), birds, dogs, cats, cars, motorcycles, bicycles, trains and airplanes), AF-area mode: Pinpoint, single-point, dynamic-area (S, M, L), wide-area (S, L, C1, C2), 3D-tracking (in Photo mode), subject-tracking (in Video mode), auto-area (100% × 90% coverage) |
| Vibration Reduction |
5-axis image sensor shift (New CIPA standard: 7.5 stops at center, 6.0 stops at edges), Synchro VR, focus point VR; No electromagnetic lock |
| Monitor |
4.0-in. (16:10), approx. 3070k-dot vari-angle touch-sensitive LCD |
| Power source |
EN-EL15c, EN-EL15b (with ID and fuel gauge (FG) functions, support for USB charging while the camera is turned off and USB power delivery while on), EN-EL15a (with ID and FG functions, USB power delivery is possible but USB charging is not), support for EH-8P AC adapters |
| Interface |
Type-C USB (USB 3.2), Type-D HDMI, external stereo mic (line input supported), and headphone (remote cord) connectors; digital accessory shoe; Wi-Fi and Bluetooth modules |
| Dust- and drip-resistance |
Magenisum alloy body |
| Communication |
Support for computer, FTP server, camera, and smart device connection, and Cloud collaboration |
| Dimensions (WxHxD) |
Approx. 13.4 cm × 8.05 cm × 4.9 cm |
| Weight |
Approx. 0.540 Kg (camera body only), 0.630 Kg (with battery and 2 memory cards) When the body cap and digital accessory shoe cover are not attached. |
| Primary video functions |
Internal RAW (R3D NE) recording, LUT view assist (effect of LUTs can be viewed in real time while shooting; up to 30p), Red colour science (Log3G10), base ISO sensitivity control, Red-supervised Imaging Recipes, shutter angle control, vertical video recording |
| Others |
4 preset user settings ([Cinematic video], [Slow-motion video], [Starscape photo], and [Portrait]) |
| |
|
| LENS |
|
| |
|
| Focal Length |
24 to 70mm
|
| Aperture |
Maximum: f/4
|
| |
Minimum: f/22 |
| Lens Mount |
Nikon Z
|
| Lens Format Coverage |
Full-Frame
|
| Angle of View |
84° to 34° 20'
|
| Minimum Focus Distance |
30 cm
|
| Magnification |
1:3.33 Macro Reproduction Ratio
|
| |
0.3x Magnification |
| Optical Design |
14 Elements in 11 Groups
|
| Aperture/Iris Blades |
7, Rounded
|
| Focus Type |
Autofocus
|
| Filter Size |
72 mm (Front)
|
| Dimensions |
L: 8.85 cm
|
| Weight |
0.500 kg
|
