| Lens Mount |
Canon RF
|
| Sensor Resolution |
Actual: 21.4 Megapixel
|
| Effective: 20.1 Megapixel (5472 x 3648) |
| Image Sensor |
36 x 24 mm (Full-Frame) CMOS
|
| Sensor Crop (35mm Equivalent) |
Crop Factor: 1x
|
| *Additional Crop Occurs in Select Video Modes |
| Image Stabilization |
Sensor-Shift, 5-Axis
|
| Built-In ND Filter |
No
|
| Capture Type |
Stills & Video
|
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
| Shutter Speed |
Mechanical Shutter
|
| 1/8000 to 30 Seconds |
| Electronic Front Curtain Shutter |
| 1/8000 to 30 Seconds |
| Electronic Shutter |
| 1/8000 to 0.5 Seconds |
| Bulb/Time Mode |
Bulb Mode
|
| ISO Sensitivity Range |
|
| 100 to 102,400 in Auto Mode (Extended: 100 to 204,800) |
| Video |
| 100 to 25,600 (Extended: 100 to 204,800) |
| Metering Method |
Center-Weighted Average, Evaluative, Partial, Spot
|
| Exposure Modes |
Aperture Priority, Auto, Manual, Program, Shutter Priority
|
| Exposure Compensation |
-3 to +3 EV (1/3, 1/2 EV Steps)
|
| Metering Range |
-3 to 20 EV
|
| White Balance |
Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten
|
| Continuous Shooting |
Mechanical Shutter
|
| Up to 12 fps at 20 MP for up to 1000 Frames (JPEG) / 240 Frames (Raw) |
| Electronic Shutter |
| Up to 20 fps at 20 MP for up to 1000 Frames (JPEG) / 240 Frames (Raw) |
| Interval Recording |
Yes
|
| Self-Timer |
2/10-Second Delay
|
| Image Sizes |
3:2 Raw
|
| 20 MP (5472 x 3648) |
| 3:2 JPEG |
| 20 MP (5472 x 3648) |
| 8.9 MP (3648 x 2432) |
| 5 MP (2736 x 1824) |
| 3.8 MP (2400 x 1600) |
| 4:3 JPEG |
| 17.7 MP (4864 x 3648) |
| 7.9 MP (3248 x 2432) |
| 4.4 MP (2432 x 1824) |
| 3.4 MP (2112 x 1600) |
| 16:9 JPEG |
| 16.8 MP (5472 x 3072) |
| 7.5 MP (3648 x 2048) |
| 4.2 MP (2736 x 1536) |
| 3.2 MP (2400 x 1344) |
| 1:1 JPEG |
| 13.3 MP (3648 x 3648) |
| 5.9 MP (2432 x 2432) |
| 3.3 MP (1824 x 1824) |
| 2.6 MP (1600 x 1600) |
| Aspect Ratio |
1:1, 4:3, 16:9
|
| Image File Format |
HEIF, JPEG, Raw
|
| Bit Depth |
14-Bit
|
| Internal Recording Modes |
H.264 4:2:0 8-Bit
|
| UHD 4K (3840 x 2160) at 23.98/29.97/59.94 fps [120 to 230 Mb/s] |
| 1920 x 1080p at 23.98/29.97/59.94 fps [12 to 120 Mb/s] |
| H.265 4:2:2 10-Bit |
| UHD 4K (3840 x 2160) at 23.98/29.97/59.94 fps [170 to 340 Mb/s] |
| 1920 x 1080p at 23.98/29.97/59.94 fps [28 to 180 Mb/s] |
| External Recording Modes |
4:2:2 10-Bit via HDMI
|
| UHD 4K (3840 x 2160) up to 59.94 fps |
| Gamma Curve |
Canon Log
|
| Recording Limit |
Up to 30 Minutes
|
| IP Streaming |
No
|
| Built-In Microphone |
Stereo
|
| Audio Recording |
AAC Audio
|
| LPCM Audio |
| Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC (UHS-II)
|
| Video I/O |
1x Micro-HDMI (Unspecified Signal) Output
|
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
|
| 1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
| Power I/O |
1x USB-C Input/Output
|
| Other I/O |
1x USB-C (USB 3.2 / 3.1 Gen 1) Data Input/Output (Shared with Power Input)
|
| 1x Canon E3 (2.5 mm Sub-Mini) Input |
| Wireless |
Wi-Fi 4 (802.11n), Bluetooth 4.2
|
| Mobile App Compatible |
Yes: Android & iOS
|
| App Name: Canon Connect Camera |
| Functionality: Access Stored Files, Adjust Settings, Firmware Update, Remote Control, View Live Feed |
| Global Positioning (GPS, GLONASS, etc.) |
GPS
|
| *Via Connected Smartphone |
| Display Size |
3.0"
|
| Resolution |
1,620,000 Dot
|
| Display Type |
Free-Angle Tilting Touchscreen LCD
|
| Type |
Built-In Electronic (OLED)
|
| Size |
0.5"
|
| Resolution |
3,690,000 Dot
|
| Eye Point |
23 mm
|
| Coverage |
100%
|
| Magnification |
Approx. 0.76x
|
| Diopter Adjustment |
-4 to +2
|
| Focus Type |
Auto and Manual Focus
|
| Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF
|
| Autofocus Points |
Phase Detection: 1053
|
| Autofocus Sensitivity |
-6.5 to +20 EV
|
| Built-In Flash/Light |
No
|
| Maximum Sync Speed |
1/250 Second
|
| Flash Compensation |
-3 to +3 EV (1/3, 1/2 EV Steps)
|
| Dedicated Flash System |
eTTL
|
| External Flash Connection |
Shoe Mount
|
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Operating Humidity |
0 to 85%
|
| Battery Type |
1x LP-E6NH Rechargeable Lithium-Ion
|
| Shoe Mount |
1x Hot Shoe
|
| Tripod Mounting Thread |
1x 1/4"-20 Female (Bottom)
|
| Material of Construction |
Magnesium Alloy, Polycarbonate
|
| Dimensions (W x H x D) |
138 x 97.5 x 88.4 mm
|
| Weight |
680 g (With Battery, Recording Media)
|
