Focal Length
35mm Equivalent Focal Length |
150-400mm（with a built-in teleconverter: 187.5-500mm）
300-800mm equivalent（with a built-in teleconverter: 375-1000mm） |
| Lens Construction |
28 elements in 18 groups (Built-in teleconverter: 7 elements in 4 groups)
(1 EDA lens, 4 Super ED lenses, 2 ED lenses, 2 HR lenses, 1 HD lens) |
| Splashproof Type / Dustproof |
IEC Standard publication 60529 IPX1
(applies when the lens is used with Olympus splashproof Body) / Dustproof construction |
| Focusing System |
High-speed Imager AF (MSC) |
| Angle of View |
8.2 degrees - 3.1 degrees (with a built-in teleconverter: 6.6 degrees - 2.5 degrees) |
| Closest Focusing Distance |
1.3m (with / without a built-in teleconverter, throughout the zoom range) |
Maximum Image Magnification
35mm Equivalent Max. Image Magnification |
Wide:0.12x / Tele:0.29x (with a built-in teleconverter: Wide:0.15x / Tele:0.36x)
Wide:0.25x / Tele:0.57x (with a built-in teleconverter: Wide:0.31x / Tele:0.71x) |
| Minimum Field Size |
Wide:139.5×104.8mm / Tele:60.7×45.6mm
(with a built-in teleconverter: Wide:111.6×83.9mm / Tele:48.6×36.5mm) |
| Number of Blades |
9 (circular aperture diaphragm) |
| Maximum Aperture |
F4.5 (with a built-in teleconverter: F5.6) |
| Minimum Aperture |
F22 (with a built-in teleconverter: F29) |
| Lens IS Mechanism |
VCM |
| IS Performance |
5-axis sync IS 8 steps*
- According to CIPA standards. When attached to OM-D E-M1X, with yaw and pitch applied to camera, half-press IS set to Off, and focal length set to 150mm.
5-axis sync IS 6 steps*
- According to CIPA standards. When attached to OM-D E-M1X, with yaw and pitch applied to camera, half-press IS set to Off, and focal length set to 400mm. (with a built-in teleconverter: 500mm)
Lens IS 4.5 steps*
- Focal length : 400mm (with a built-in teleconverter: 500mm)
|
| Filter Size |
Diameter 95 mm |
| Dimensions |
Ø115.8×314.3mm |
| Weight |
1,875g (without Lens Cap, Lens Rear Cap and Lens Hood) |
|
|
