Type | Roof Prism |
Magnification | 10x |
Objective lens diameter | 42 mm |
Exit pupil diameter | 4.2 mm |
Real field of view | 6.2-degree |
Apparent angle of view | 56.9-degree • Figure based on ISO 14132-1:2002 calculation. |
Field of view at 1,000m | 108 m |
Relative brightness | 17.6 |
Eye relief | 16 mm |
Diopter adjustment range | -2-+2 |
Eye interval adjustment range | 56-70 mm |
Close focusing distance | 1.5 m |
Weight | 665 g |
Width | 131 mm • Size is measured by eye interval adjustment at max. (mm) and eyecup (turn-and-slide) at min. length (mm). |
Height | 140 mm • Size is measured by eye interval adjustment at max. (mm) and eyecup (turn-and-slide) at min. length (mm). |
Depth | 53 mm • Size is measured by eye interval adjustment at max. (mm) and eyecup (turn-and-slide) at min. length (mm). |
Lens construction | 9 Elements in 7 Groups |
Coating | Full multi-coating, Phase-correction Coating, Dielectric multilayer prism coating, Water & oil repellent coating, ZERO Coating |
ED Lens | With |
Waterproof | With • Waterproof designed by nitrogen-filled body, and can be submerged to a depth of 1 meter for up to 5 minutes. But can be not used in underwater. |
Strap width | 12 mm |
