Binocular Type | Roof Prism type |
Magnification | 10x |
Effective diameter of objective lens | 25mm |
Diameter of exit pupil | 2.5mm |
Actual field of view | 6.5-degree |
Field of view at 1000m | 114m |
Relative Brightness | 6.3 |
Eye-relief | 12mm |
Diopter adjustment range | ±3dpt |
Eye interval adjustment range | 35mm to 73mm |
Closest Focusing Distance | 1.5m to ∞ |
Weight | 260g |
Width (at maximum eye interval) | 107mm |
Length (when eyecups are retracted) | 104mm |
Thickness (at maximum eye interval) | 44mm |
Lens composition | Eyepiece: 4 elements in 3 groups, Objective lens: 4 elements in 3 group |
Coating | Multi-coating on all surfaces, Roof prism: phase coating |
