Leofoto NB-40 Ball Head

Product Code: 115131
inc GST
Increase value Decrease value
Found a better price? We'll match it!* Price Match Now
  • Product Description
  • Specifications
  • What's in the Box?

Leofoto NB-40 Ball Head

Key Features
  • Load Capacity: 44.1 lb
  • Height: 2.7"
  • Weight: 18.3 oz
  • Arca-Type Compatible
  • 360° Pan with Independent Pan Lock
  • Double Notch at Base for Tilting 90°
  • Friction Control Knob
  • Bubble Level & Distance Markings at Top
  • 3/8"-16 Tripod Mounting Thread
  • Anodized Aluminum Construction
  • Uses a knob-driven clamp and a quick release plate to secure equipment as heavy as 44.1 lb
  • Low height of 2.7", with a weight of 18.3 oz and a ball diameter of 1.6" that lends it increased stability
  • Compatible with most Arca-type quick release plates
  • Capable of 360° panning, with two notches on the base that allow the head to reach a tilt angle of 90°
  • Three knobs for position adjustment, offering independent pan movement and tension control when used in conjunction
  • Bubble level and distance markings at the top, next to the plate, for improved use
  • Made of durable anodized aluminum, fits tripods with a 3/8"-16 mount

Securing gear with a knob-driven clamp, the LH-40 Low Profile Ball Head from Leofoto comes with a quick-release plate that goes on your camera for easy attachment and detachment while shooting. With a fixed height of 2.7" and a large ball diameter of 1.6", the low-profile design of this ball head allows it to safely support equipment as heavy as 44.1 lb.

The LH-40 is compatible with Arca-type plates and features a bubble level as well as distance markings at the top right next to where the plate is attached. A large knob on the right side is used for panning 360°, with notches on the base enabling 90° tilt in two directions for easy portrait shooting. Independent pan lock and friction control knobs are also available and can be used to easily fine-tune your composition. With a weight of 18.3 oz, the ball head is made of anodized aluminum for durability and goes on any tripod with a 3/8"-16 screw. It features a classic black-anodized finish for stylish looks as well as high performance.

Head Type    Ball Head
Base Mount    3/8"-16 Female
Quick Release Plate Type    Arca-Type
Load Capacity    44.1 lb / 20 kg
Number of Bubble Levels    1
Friction Control    Yes
Independent Pan Lock    Yes
Material    Aluminum
Pan & Tilt Range
Vertical Tilt    90°
Panning Range    360°
Physical
Ball Sphere Diameter    1.6" / 4 cm
Base Diameter    2.2" / 5.7 cm
Weight    18.3 oz / 520 g
Packaging Info
Package Weight    1.6 lb
Box Dimensions (LxWxH)    6.4 x 4.7 x 4.5"
  • Quick Release Plate (Black)
  • Quick Release Plate
