DJI Mic 3 Transmitter

Key Features

For Mic 3 Wireless System
Transmitter with Onboard Recording
Built-In Omnidirectional Microphone
Dual-Band Wireless and Bluetooth 5.4
1312' Transmission Distance
32-Bit Float Recording
Embedded Timecode Support
8-Hour Battery Life

The DJI Mic 3 Clip-On Transmitter/Recorder is a transmitter with both built-in microphone and onboard recording capabilities for seamless audio recording. Use in tandem with a separately available receiver or expand your preexisting Mic 3 wireless system. The transmitter utilizes dual-band 2.4 and 5.8 GHz technology, as well as Bluetooth 5.4 technology, to communicate with the receiver, or even directly to your DJI Osmo series camera from up to 1312' away.

Wireless Technology	Digital 2.4/5.8 GHz / Bluetooth
Diversity	Non-Diversity
Max Operating Range	1312.3' / 400 m (Line of Sight) 262.5' / 80 m (with Obstruction)
Included Transmitters	1x Clip-On with Microphone
Microphone Type	1x Built-In (Clip-On Transmitter)

System

Wireless Technology	Digital 2.4/5.8 GHz / Bluetooth
Diversity	Non-Diversity
RF Frequency Band	2400 to 2483 MHz / 5150 to 5850 MHz
RF Channel Scanning	Auto-Scan
Max Operating Range	1312.3' / 400 m (Line of Sight) 262.5' / 80 m (with Obstruction)
Max Transmitters per Band	4
Built-In Recorder	Yes (on Transmitter)
Timecode Support	Yes
Mobile App Compatible	Yes: Android & iOS App Name: DJI Mimo

Transmitters

Included Transmitters	1x Clip-On with Microphone
Antenna	Internal
Input Level	Line
Audio I/O	No
USB I/O	No
Muting	Off/On Switch
Auto-Level/Gain	Yes
Sync Method	2.4 GHz QPSK
Display	Single-LED Indicators Only

Microphones

Microphone Type	1x Built-In (Clip-On Transmitter)
Polar Pattern	Omnidirectional
Maximum SPL	126 dB
Sensitivity	-36 dBV (@ 1 kHz, 94 dB SPL)
Color	Black

Power

Transmitter Battery Type	1x Built-In Rechargeable - 137 mAh
Transmitter Battery Life	8 Hours
Battery Charging Time	50 Minutes
AC/DC Power Adapter	No
Input Power	5 VDC

Physical

Environmental Resistance	No
Dimensions	1.1 x 1.1 x 0.6" / 28.8 x 28.3 x 16.4 mm
Weight	0.6 oz / 16 g

Packaging Info

Package Weight	0.23 lb
Box Dimensions (LxWxH)	4.9 x 4.8 x 1.9"
