Canon EOS C80 Cinema Camera

Key Features

6K Full-Frame CMOS Sensor with DIGIC DV7 Processor
Dual Pixel CMOS AF II with Advanced Subject Detection
4K 120p and 6K Oversampled Recording for Stunning Image Quality
Compact, Lightweight Design for Handheld and Gimbal Use
Canon Log 2 & 3 with 16-Stop Dynamic Range
Versatile ISO Modes and Mechanical ND Filter
Dual SD Card Slots for Simultaneous Recording
Built-In Wi-Fi, Timecode, and Multiple Connectivity Options

The Canon EOS C80 Cinema Camera combines cutting-edge technology with a compact, portable design, making it an ideal solution for professional filmmakers seeking high-performance specs in a versatile package. Equipped with a 6K full-frame back-illuminated CMOS sensor and the powerful DIGIC DV7 processor, the C80 delivers stunning image quality with 6K oversampling for enhanced 4K resolution. Whether you're shooting a feature film or high-paced sports, the 4K 120p recording mode ensures you capture every detail in smooth, high-resolution motion.

One of the standout features of the EOS C80 is Dual Pixel CMOS AF II, which utilizes deep learning algorithms to offer fast and precise subject detection and autofocus. This makes it easy to track moving subjects, ensuring you never miss a shot. Paired with RF lenses, this system enables seamless communication between the camera and the lens, providing enhanced image stabilization and making operation intuitive.

The C80 also offers exceptional flexibility for both video and photography, with Canon Log 2 & Log 3 allowing for a wide dynamic range of up to 16 stops, perfect for color grading and post-production. The camera’s versatile ISO modes allow for performance in low-light environments, and the built-in mechanical ND filter (up to 10 stops) helps control exposure in bright conditions.

Designed with mobility in mind, the compact, lightweight body of the EOS C80 is perfect for handheld shooting or mounting on gimbals, drones, or rigs, reducing operator fatigue. The camera also features dual SD card slots for simultaneous recording of 6K RAW, XF-AVC, and proxy data, making it easy to streamline your workflow in post-production.

The EOS C80 offers multiple connectivity options, including mini-XLR inputs, HDMI, SDI output, USB Type-C, and Timecode (BNC), along with built-in Wi-Fi for remote control and monitoring. This robust feature set ensures that the C80 can handle any production setup, from run-and-gun filmmaking to complex studio environments.

With its advanced features, compact design, and unparalleled image quality, the Canon EOS C80 is a versatile, high-performance cinema camera that’s ready to meet the demands of modern filmmakers.

Lens Mount	Canon RF
Lens Communication	Yes, Cooke /i
Sensor Resolution	Actual: 26.67 Megapixel (6202 x 4300)
Sensor Resolution	Effective: 19.05 Megapixel (6008 x 3170)
Image Sensor	Full-Frame BSI Stacked CMOS
Image Stabilization	Digital, 5-Axis
Built-In ND Filter	Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64), 8-Stop (1/256), 10-Stop (1/1024) ND Filters
Internal Filter Holder	No
Capture Type	Stills & Video
Shutter Type	Electronic Rolling Shutter
Shutter Speed	1/2000 to 1 Second
ISO Sensitivity Range	100 to 102,400
Shutter Angle	11.25 to 360°
Advertised Dynamic Range	16 Stops
Signal-to-Noise Ratio	67 dB
White Balance	2000 to 15,000K
White Balance	Presets: AWB, Daylight, Set A, Set B, Tungsten
Internal Recording Modes	Cinema RAW Light 12-Bit
	UHD 6K (6000 x 3164) at 23.98/24.00/25/29.97 fps [553 to 639 Mb/s]
	4368 x 2304 at 23.98/24.00/25/29.97/50/59.94 fps [293 to 678 Mb/s]
	XF-HEVC S Long GOP 4:2:2 10-Bit
	4096 x 2160 at 50/59.94/120 fps [225 Mb/s]
	3840 x 2160 at 23.98/24.00/25/29.97/120 fps [135 Mb/s]
	2048 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s]
	1920 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s]
	XF-HEVC S Long GOP 4:2:0 10-Bit
	4096 x 2160 at 50/59.94/120 fps [150 Mb/s]
	3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s]
	2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s]
	1920 x 1080 at 23.98/24.00/25/29.97/59.94/180 fps [35 Mb/s]
	XF-HEVC S Long GOP 4:2:0 10-Bit
	2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s]
	1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [9 to 16 Mb/s]
	XF-HEVC S Long GOP 4:2:0 8-Bit
	1280 x 720 at 23.98/24.00/25/50/59.94 fps [6 Mb/s]
	XF-AVC S Intra 4:2:2 10-Bit
	4096 x 2160 at 59.94/60.00 fps [600 Mb/s]
	3840 x 2160 at 50/60.00 fps [500 Mb/s]
	2048 x 2160 at 59.94/120 fps [300 Mb/s]
	1920 x 1080 at 50/120 fps [250 Mb/s]
	XF-AVC S Intra 4:2:2 10-Bit
	4096 x 2160 at 50/59.94/120 fps [250 Mb/s]
	3840 x 2160 at 23.98/24.00/25/29.97/120 fps [150 Mb/s]
	2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [50 Mb/s]
	1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [120 to 300 Mb/s]
	XF-AVC S Long GOP 4:2:0 8-Bit
	4096 x 2160 at 50/59.94/120 fps [150 Mb/s]
	3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s]
	2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s]
	1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s]
	XF-HEVC S Intra 4:2:0 8-Bit
	2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [9 to 16 Mb/s]
	1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s]
	1280 x 720 at 23.98/24.00/25/29.97/50/59.94 fps [6 Mb/s]
External Recording Modes	SDI/BNC / HDMI / USB
External Recording Modes	4096 x 2160
Recording Sensor Crop	Crops to Output Resolution When Using Super35 Mode
Fast-/Slow-Motion Support	Yes
Gamma Curve	Canon Log 2, Canon Log 3, HDR-HLG, Rec709, Rec2020
Broadcast Output	NTSC/PAL
Built-In Microphone	Stereo
Audio Recording	Cinema RAW Light: 4-Channel 24-Bit 48 kHz LPCM Audio
	XF-AVC: 4-Channel 24-Bit 48 kHz LPCM Audio
	XF-AVC S, XF-HEVC S: 4-Channel 24-Bit 48 kHz LPCM Audio
	XF-AVC S, XF-HEVC S: 2-Channel 16-Bit 48 kHz AAC Audio
IP Streaming	H.264, MPEG2, RTP, RTSP, SRT, UDP
IP Streaming	1920 x 1080 at 50i, 50p, 59.94i, 59.94p (4.0 to 9.0 Mb/s)
Image File Format	JPEG
Media/Memory Card Slot	Slot 1: SD/SDHC/SDXC
Media/Memory Card Slot	Slot 2: SD/SDHC/SDXC
Video I/O	1x BNC (12G-SDI) Output
	1x BNC (3G-SDI) Monitor Output
	1x HDMI (Unspecified Signal) Output
Audio I/O	2x Mini XLR Input
	3.5 mm TRS Stereo Headphone Output
	3.5 mm TRS Stereo Microphone Input on Camera Body
Power I/O	1x Barrel (23.7 to 25VDC) Input
Other I/O	1x RJ45 (XC) Control
	1x USB-C Monitor
	1x BNC (Timecode)
	1x 2.5 mm Sub-Mini (LANC) Control
Wireless	2.4 / 5 GHz Wi-Fi 5 (802.11ac)
Mobile App Compatible	Yes: iOS Only
	App Name: Remote Camera Control App
	Functionality: Adjust Settings, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)	No
Display Type	Included External Touchscreen LCD
Display Size	3.5"
Resolution	1280 x 720
Focus Type	Auto and Manual Focus
Focus Mode	Continuous-Servo AF, Focus Lock AF Area Mode, One-Shot AF
Operating Conditions	0 to 40°C up to 85% Humidity
Storage Conditions	-5 to 45°C up to 60% Humidity
Battery Type	Canon BP-AN Series
Shoe Mount	1x Intelligent Hot Shoe
Tripod Mounting Thread	1x 3/8"-16 Female
Tripod Mounting Thread	2x 1/4"-20 Female
Accessory Mounting Thread	No
Dimensions (W x H x D)	160 x 138 x 116 mm
Dimensions (W x H x D)	276 x 173 x 160 mm (With Handle, Included Battery, Mic Holder)
Weight	1.30 kg (Body Only)
Weight	1.545 kg (With Battery, Handle)
