OM System 90mm ED F3.5 IS Pro Micro 4/3 Macro Lens

118064

inc GST
Increase value Decrease value
Found a better price? We'll match it!* Price Match Now
  • Product Description
  • Specifications
  • What's in the Box?
  • Warranty

OM System ED 90mm F3.5 IS Pro Macro Lens

Key Features
  • Micro Four Thirds | f/3.5 to f/22
  • 180mm (Full-Frame Equivalent)
  • Telephoto Macro Lens
  • 2:1 Magnification, 8.8" Min. Focus
  • MSC AF System & Manual Focus Clutch
  • Optical Image Stabilization
  • IP53 Weather-Sealing, Fluorine Coating
  • ED and HR Elements & ZERO Coating
  • Focus Limit Switch & Lens Fn Button
  • Rounded 7-Blade Diaphragm
  • Offering up to 2x magnification, this lens can reproduce virtually microscopic subjects with greater-than-life-size rendering, making it perfect for highlighting details of small subjects like flowers, insects, coins, and other intricate objects.
  • Minimum focusing distance of 8.8" translates to a minimum working distance of about 3.5" from the front of the lens.
  • Manual focus clutch mechanism reveals magnification and focus distance markings on the lens barrel for easier recognition of focusing position.
  • Floating focus design maintains sharpness throughout the focusing range, offering matched image quality from minimum focusing distance up to infinity.
  • When used with the optional MC-14 or MC-20 Teleconverter, the effective maximum magnification can be increased to 2.8x or 4x, respectively.
  • Optical design includes a variety of extra-low dispersion and high refractive index glass elements to reduce various aberrations and produce imagery with a high degree of clarity, color accuracy, and sharpness.
  • Optical design has been optimized to suppress chromatic aberrations and color fringing at close range for more realistic and detailed rendering.
  • ZERO (Zuiko Extra-low Reflection Optical) coating suppresses flare and ghosting for greater contrast and color fidelity when working in strong lighting conditions.


Designed for ultra-high magnification shooting and built for adventures, the M.Zuiko Digital ED 90mm f/3.5 Macro IS PRO, from OM SYSTEM, is the ideal field macro lens for Micro Four Thirds shooters. This telephoto prime mixes a 180mm-equivalent focal length with a 2:1 maximum magnification for close-up shooting at a greater-than-life-size scale. Coupled with an intuitive manual focus clutch mechanism, quick AF performance, and optical image stabilization, this is a versatile lens for handheld shooting and IP53 weather sealing makes it suitable for use in harsh weather conditions.

Focal Length
90mm (35mm Equivalent: 180mm)
Maximum Aperture
f/3.5
Lens Mount
Micro Four Thirds
Lens Format Coverage
Micro Four Thirds
Focus Type
Autofocus
Image Stabilization
Yes
Filter Size
62 mm (Front)
Maximum Aperture
f/3.5
Minimum Aperture
f/22
Lens Mount
Micro Four Thirds
Lens Format Coverage
Micro Four Thirds
Angle of View
14°
Minimum Focus Distance
8.8" / 22.4 cm
Maximum Magnification
2x
Macro Reproduction Ratio
2:1
Optical Design
18 Elements in 13 Groups
Diaphragm Blades
7, Rounded
Focus Type
Autofocus
Image Stabilization
Yes
Filter Size
62 mm (Front)
Dimensions (ø x L)
2.7 x 5.4" / 69.8 x 136 mm
Weight
1 lb / 453 g
Packaging Info
Package Weight
1.635 lb
Box Dimensions (LxWxH)
7.7 x 5.7 x 4.5"
  • 1x LH-66E Lens Hood
  • 1x LC-62G Lens Cap
  • 1x LR-2 Lens Rear Cap
  • 1x CS-53 Wrapping Cloth
  • 1x Instruction Manual
